Description
Precise beveling from 0–90° enables accurate V and Y bevel preparation for a wide range of applications.
Cold milling process produces a clean, non-oxidized surface that meets strict welding industry requirements.
High-quality surface finish from the precision milling cutter improves weld edge preparation and consistency.
Clad removal capability removes Inconel cladding up to 1.6” (40 mm) for demanding fabrication applications.
Processes a wide range of materials, including any kind of steel and exotic alloy, aluminum products, aluminum alloy, and copper.
Automatic feed system provides consistent, hands-free operation with speeds up to 1500 mm/min for increased productivity.
Real-time control of feed and cutting speeds displayed on the machine screen for optimal performance and flexibility.
Easy 0–90° bevel angle adjustment with an integrated angle ruler for fast, accurate setup and repeatable results.
Quick height adjustment using a manual handle ensures proper alignment with different plate thicknesses.
Secure electrical clamping system stabilizes the machine on the plate for precise and reliable milling.
High-speed milling head with replaceable inserts delivers efficient cutting and can be adapted to different materials.
Metal swivel castors allow easy positioning and movement of the machine, while metal housing and melt-resistant wheels ensure smooth, stable travel along the plate during beveling.
Electric-powered system (400V or 480V) suitable for industrial fabrication environments.
Versatile across industries, including engineering machinery, steel structures, pressure vessels, shipbuilding, and aerospace.
Complete ready-to-use package including milling head, tool kit, metal wheels, documentation, and protective wooden transport box.
Optional transportation box with ramp (Part No. EM90RB) simplifies machine loading and unloading while providing durable protection during transport and storage.
Optional 90° clad removal milling head (Part No. CL400R-63) with five screw-fixed inserts enables efficient clad removal, with insert options available to match different clad materials.
